Tesla Model 3 Headlight Replacement: A Step-by-Step Guide

Replacing the headlights on a Tesla Model 3 may sound like a daunting task, but it is actually a simple process that can be done with the right tools and a bit of know-how. In fact, it can be a cost-effective DIY project for those who are running low on funds but still need to add new headlights to their car.

The process involves six steps, including removing the plastic panel, taking out the bumper, detaching the old headlights, adding the new headlights, installing a ludicrous harness, and finally putting all the parts back in place. This guide will provide an overview of the process and offer additional information on the cost of replacing headlights on a Tesla Model 3, whether it is done by an expert or as a DIY project.

Easiest Tesla Model 3 Headlight Replacement Method

If you’re looking to replace the headlights on your Tesla Model 3, you’re in luck. With the right tools and some patience, you can easily replace the headlights at home. Here’s a step-by-step guide to help you get started.

Tools Required

Before you begin, make sure you have the following tools:

• A pair of gloves
• OEM headlights
• Flat-head screwdriver
• Philips screwdriver
• Plastic pry bar
• Socket extensions
• 1/4″ or 3/8″ ratchet
• 10mm socket
• Flush cuts
• Plastic tray or sealable bags
• A clean cloth
• Glass cleaner
• Masking tape
• APE ethernet cable

Step 1: Take Out the Plastic Panel/Tub

To start, power off your Tesla and cover your hands with gloves. Open the hood using the app or key fob and pull the top cowl off using your bare hands. Detach the frunk latch and take out the plug. Press the 2 plastic tabs that hide the 10 mm bolts underneath (on the top of the storage cover). Grab the 10 mm socket to detach the bolts. You’ll now find another 2 bolts right in the front next to the frunk latch part. Detach the air intake cabin in the top part. Then, you’ll find a 10 mm bolt close to the master cylinder res. and unscrew it using the 10 mm socket. Take out the mat from the frunk storage to find 2 bolts at the bottom. Unscrew them using the 10 mm socket. At the top-corner section, pull up the whole front cover that hides the interior parts. If needed, use a plastic pry bar.

Step 2: Detach the Bumper

Next, you’ll need to detach the bumper. You’ll find six 10 mm bolts on top of the bumper. Detach them using the 10 mm socket. Store the bolts in a plastic tray or sealable bag. If possible, place a sticker or name the stored 6 bolts in separate tags to identify each bolt without being confused. Go down near the front-right wheel side, take a flat-head Philips screwdriver, and simply pop up the tabs on the 3 clips on the fender liner side. If needed, use the pry bar to do it easily. Pull out the fender liner using your hand. You’ll now locate three 10 mm bolts that hold the bumper to the fender area. Insert a 10 mm socket in the 1/4” or 3/8” ratchet and then remove the 3 bolts. Using the same tool, take out the one 10 mm nut on the rear corner of the bumper. Do the same procedure on the opposite (front-left) side of the Model 3. Using the Philips screwdriver and a separate flat-head screwdriver, detach the clips on the bottom front of the bumper. Just use the flathead screwdriver on the gap of clips and place a Philips screwdriver in middle to detach them. Put on masking tape on the border of the fender to avoid catching scratches upon the bumper removal. Repeat the same thing on the opposite side of Model 3. Take out the bumper away from the fender carefully and store it in a safe spot. Make sure to use slight force to do it easily. If possible, ask a friend to help you remove the bumper in a safe way. Detach the fog light harness plug using a flat-head screwdriver.

Step 3: Remove the Headlights

Now it’s time to remove the headlights. Spot 2 main bolts (10 mm) that hold the right headlight assembly. Take the 10 mm socket to remove these bolts. Be sure to use your leg to hold the headlight while removing the bolts to avoid falling out. Detach the OEM left headlight assembly. Unplug the harness plug using the flat-had screwdriver toward the tab. Do the same procedure on the opposite side to detach the OEM left headlight assembly. Store them in a good spot.

Step 4: Install the New Headlights

Once you’ve removed the old headlights, it’s time to install the new ones. Insert the front-right headlight assembly on the right side. Be sure to align the dowel into the grommet on the fender to ensure proper fitting. Insert the two 10mm bolts and tighten them out using the socket. Repeat the above steps to install the front-left headlight assembly on the left side.

Step 5: Add Ludicrous Harness

Next, adjust the ludicrous harness inside the frunk front side and use zip ties to adjust the position (if needed). Insert one side of the ludicrous harness on the bottom of the right headlight and another side on the

Tesla Model 3 Headlight Replacement Cost Idea

The cost of replacing a Model 3 headlight can vary depending on where the replacement is done. If done in an auto shop or regular store, the replacement of a single headlight can cost between $900 to $1,500, including tax and labor costs. However, if done at a Tesla Service Center, the cost will be between $1,050 to $1,400, including parts, labor, and VAT. The cost of parts alone for a single headlight replacement is $900 to $1,200 in the DIY method. It is worth noting that professional replacement is recommended for the best results.

Can You Upgrade Model 3 Headlights?

Yes, it is possible to upgrade the headlights on a Model 3, but it is a difficult task that should only be attempted by an expert. The process involves measuring and mounting the new headlights at a straight level, dealing with the wiring harness inside the bumper that goes into the left and right headlights, and wiring the can interface, which later needs to be flashed using a flashing remote and updated into the latest software version to detect rightly.

After the installation, two switches need to be installed inside the Tesla interior area, which might need making holes. However, it is important to note that this kind of action will void the warranty, and Tesla won’t cover any free repair service for that.

It is worth noting that the new Tesla Matrix Headlights are a significant upgrade from the old LED headlights. The new headlights are adaptive in nature and will follow the curve of the road and adjust the beam automatically to prevent the oncoming traffic from getting blind.

Wrapping Up

Replacing a Tesla Model 3 headlight can be a daunting task, but it need not take more than 30-40 minutes. In case you find the process challenging, do not hesitate to seek professional help. It is important to note that upgrading an old Model 3 may violate the warranty, so it is best to avoid doing so. During the process, it may be necessary to have someone help you carry the bumper. Overall, this guide should help you replace your Tesla Model 3 headlight with ease and confidence.

Frequently Asked Questions

What is the typical cost range for replacing a Tesla Model 3 headlight?

The cost of replacing a Tesla Model 3 headlight can vary depending on the extent of the damage and the type of headlight being replaced. On average, the cost can range from $500 to $1,500, which includes the cost of labor and parts.

Are there any recommended headlight replacement kits for the Tesla Model 3?

There are several headlight replacement kits available on the market for the Tesla Model 3. However, it is recommended to use OEM (Original Equipment Manufacturer) parts for a perfect fit and optimal performance.

Can I upgrade the headlights on my Tesla Model 3 to a higher quality or brighter option?

Yes, it is possible to upgrade the headlights on a Tesla Model 3 to a higher quality or brighter option. However, it is important to ensure that the upgraded headlights are compatible with the vehicle’s electrical system and do not violate any regulations.

What type of headlight bulbs are used in the Tesla Model 3?

The Tesla Model 3 uses LED (Light Emitting Diode) headlight bulbs, which are energy-efficient and provide brighter illumination compared to traditional halogen bulbs.

How do I replace the headlight lens on my Tesla Model 3?

To replace the headlight lens on a Tesla Model 3, the front bumper cover needs to be removed. This requires specialized tools and knowledge, and it is recommended to seek professional assistance to avoid any damage to the vehicle.

What should I do if my Tesla Model 3 headlight is not functioning properly?

If a Tesla Model 3 headlight is not functioning properly, it is recommended to first check the headlight bulb and wiring for any damage or loose connections. If the issue persists, it is best to seek professional assistance to diagnose and repair the problem.
